La batería recargable de ácido de plomo sellada FGET (batería VRLA) es a prueba de fugas y no requiere mantenimiento. La superioridad de la batería VRLA se deriva de su tecnología de recombinación de oxígeno excepcionalmente eficiente.
Identificación del artículo :
FGET 6FM5Capacidad :
5ahTamaño :
90*70*101*107Peso :
1.6OEM y ODM :
AvaliableCertificados :
ISO9001:2008,TS16949:2009,CE,RoHSLa orden mínima :
100pcsTiempo de espera :
15 daysverde futuro 12V 5AH Tipo B Ventas superiores Batería de UPS VRLA de plomo ácido sellada
Aplicación principal y características generales de la serie de baterías AGM:
Esta batería de ácido de plomo sellada recargable de 12 V es un reemplazo compatible para las baterías Ritar RT1250. El voltaje, la capacidad y las dimensiones físicas de esta batería de alta calidad son casi idénticos a los de la batería Ritar RT1250. El fabricante de esta batería cuenta con la certificación ISO9001 e ISO14001 con aprobaciones UL y CE.
Uso y mantenimiento de la batería:
1) Utilice una carga de voltaje constante.
2) En carga flotante, el voltaje es de 2,23 a 2,27 por celda unitaria.
3) En uso cíclico, el voltaje es de 2,35 a 2,45 por unidad de celda, el máx. La corriente no supera el 25% ° C
4) Apriete los pernos para evitar chispas y un mal contacto cuando la batería esté en uso.
5) No lo use cerca de una fuente de calor y una llama abierta.
6) Manténgalo a baja temperatura. Cámbielo mientras haya fugas de líquido o daños.
Tamaño de la batería:
Parámetros de la batería:
1. Parámetro funcional | 5. Temperatura ambiente | ||
Voltaje nominal | 12V | Temperatura de descarga | -15~50ºC |
Capacidad Nominal (tarifa 20 horas) | 5Ah | Temperatura de carga | 0~40ºC |
Número de celdas | 6 celdas | Temperatura de almacenamiento | -15~40ºC |
2. Capacidad nominal a 25ºC (77° F) | 6. Resistencia interna y máx. Corriente de descarga | ||
Tarifa de 20 horas (0.05C, 10.8V) | 5Ah | Batería totalmente cargada a 25 ºC (77 °F) | <35mΩ |
Tarifa de 5 horas (0.165C, 10.8V) | 4.48Ah | máx. Corriente de descarga (7 min) | 14.9A |
Tarifa de 1 hora (0.55C, 10.5V) | 3.19 Ah | Corriente de cortocircuito (10 seg) | 50.0A |
3. Capacidad afectada por la temperatura (tarifa de 20 horas) | 7. Autodescarga a 25ºC (77° F) | ||
40ºC (104°F) | 103% | Capacidad después de 3 meses de almacenamiento | 91% |
25ºC (77°F) | 100% | Capacidad después de 6 meses de almacenamiento | 82% |
0ºC (32°F) | 85% | Capacidad después de 9 meses de almacenamiento | 73% |
-15ºC (5°F) | sesenta y cinco% | Capacidad después de 12 meses de almacenamiento | 64% |
4. Dimensión y Peso | 8. Carga de voltaje constante a 25ºC (77° F) | ||
Longitud | 90 mm | uso cíclico | 14,4~14,9 V |
Ancho | 70 mm | Corriente máxima de carga | 1.5A |
Altura | 101 mm | Compensación de temperatura | -30mV/ºC |
Altura total | 107 mm | uso flotante | 13,6~13,8 V |
Peso de referencia | 1,6 kg | Compensación de temperatura | -20mV/ºC |
Serie de baterías de plomo ácido:
Mas en : https://www.futuregreenbattery.com/category/downloads/1
Nuestros servicios:
Muestras y OEM, Garantía y Servicio Postventa:
Se puede proporcionar una muestra para pruebas de calidad.
Product Series | AS series small size(Capacity below 33Ah) | AM series mediuml size(6V,12V,Capacity 33Ah to 65Ah) | SL series large size(2V, Capacity above 65Ah) |
Main Applications | 1) Small UPS 2) Baby carriage, scooter, lawn mower, bag car 3) Electronic scales, portable lamps, table lamps, garden lamps, electric fans 4) Instrumentation equipment such as electronics, power tools, and electric toys, etc. 5) Car starter, generator 6) Solar/ wind energy indicator lights, signal lights, emergency lights, fire alarms and security systems 7) Consumer products supporting power supply, etc. |
1) Medium and large UPS 2) Banking, finance, traffic signals (metro, railway, highway, air station, navigation mark, etc.) system 3) Power DC screen 4) Emergency power supply (EPS) 5) DC power supply for hospitals, laboratories, schools, and research institutes 6) Electronics, equipment 7) Automation control system, etc. |
1) Communication base station/office 2) Backup power supply for power DC screen, power communication backup power supply 3) Large IDC machine room backup power supply, large UPS backup power supply 4) Solar/ wind energy off-grid energy storage system |
General Features | ●Affordable, consumer design ●Children's car, lamps, scales, etc. adopt cycle technology, deep cycle and long discharge life ●The starter adopts cast welding and wall welding technology, and has excellent super-current discharge performance. |
●High capacity design, longer standby time ●High corrosion-resistant multi-alloy grid, long life of float charge ● A variety of sizes, suitable for a variety of equipment or cabinet installation |
●Thick plate, low density, internalized design, long life of floating charge, suitable for standby power supply |
Battery Use and Maintenance:
1) Please use constant-voltage charge.
2) In floating charge, the voltage is 2.23 to 2.27 per unit cell.
3) In cycle use, the voltage is 2.35 to 2.45 per unit cell, the max. Current is no more than 25%° C
4) Please do tighten the bolts to avoid sparkle and poor contact when the battery is in use.
5) Please do not use it near the heat source and open flame.
6) Please keep it at low temperature. Please change it while there is liquid leaking or damage.
Carton Packing
20, 10 or 4 pieces in one carton for batteries smaller than 12V24AH,one in one carton for larger batteries.
Batteries Layer
Load Lead acid batteries 3-5 layers high with cardboard between each layer, and stretch wrap. Make sure to catch the top of the pallet to help anchor it.
Fumigation Free Tray
As Lead Acid batteries are very heavy, we all use fumigation free tray to transport them.
FGET, it is highly resistant to battery acid, oxidation and heat, and can maintain its shape and strength after prolonged exposure to sever environmental conditions. Customized specifications are available.
Battery Charging
In the fully charged state, the negative plate consists of lead, and the positive plate lead dioxide, with the electrolyte of concentrated sulfuric acid.
Produce line
FGET have 3 produce lines for AGM battery from 2V to 12V, GEL battery and OPzV battery.
Lead Acid Battery Factory:
Shaoguan Wengyuan Factory covers an area of 70,000 square meters and has more than 800 employees, mainly engaged in the development and production of batteries.
