G12R 565W 570W 575W 580W 585W 210-182mm Solar Cell Mono LECO N-Type BIFACIAL Half Cut Solar Panels

Adopting 210-182mm SMBB (Super Multi BusBar) Monocrystalline Half Cut N-Type Cells Technology For High Power Solar Cells, Higher Component Power Effectively Reduces System BOS Costs

  •  Item No: FG580-G12R
  •  Capacity: 565-585W
  •  Cells Number: 108Pcs
  •  Min Order: 36 PCS
  •  Module Efficiency(%): 22.52%
  •  Dimemsions: 2279*1134*34MM
  •  Weight: 31.5KG
  •  Packing Number: 36Pcs/Pallet
  •  40'HQ Container: 20 Pallets / 720 PCS
Consigue una cotización WhatsApp
G12R 565W 570W 575W 580W 585W 210-182mm Solar Cell Mono LECO N-Type BIFACIAL Half Cut Solar Panels
Advantages:
1. 132 Monocrystalline Half-Cut PERC Cells 182*105mm,, Higher Efficiency
2. Customizable All Black Design, Nice Appearance, Reduce Light Pollution
3. Junction Box Certified According To IEC 62790, IP 68 Approved, 3 Bypass Diodes
4. Glass High Transmission, Low Iron, Tempered, ARC, Transparent
5. Solar Cells: Mono
6. No. Of Cells: 132(6x18)
7. Mechanical Load Test: 5400Pa
8. Front / Back Glass : 2.0 mm Coated Tempered Glass
9. Frame: Anodized Aluminium Alloy
10. Output Cables: 4.0mm 2, 300mm (+) / 400mm (-), Length Can Be Customized.
11. Connectors: Mc4 Compatible


POWER CLASS LNCT-565ND LNCT-570ND LNCT-575ND LNCT-580ND LNCT-585ND
　 STC STC STC STC STC
Maximum power (Pmax) 565W 570W 575W 580W 585W
Open Circuit Voltage (Voc) 47.45V 47.66V 47.86V 48.07V 48.27V
Short Circuit Current (Isc) 15.09A 15.15A 15.21A 15.27A 15.33A
Voltage at Maximum power (Vmpp) 39.73V 39.92V 40.10V 40.28V 40.46V
Current Maximum Power (Impp) 14.22A 14.28A 14.34A 14.40A 14.46A
MODULE EFFICIENCY (%) 21.87% 22.07% 22.26% 22.45% 22.65%
STC: Irradiance 1000W/m², cell temperature 25ºC, AM1.5G
BIFACIAL OUTPUT-REARSIDE POWER GAIN

5%		 Maximum power (Pmax) 593W 599W 604W 609W 614W
Module Efficiency STC (%) 22.97% 23.17% 23.37% 23.57% 23.78%
15% Maximum power (Pmax) 650W 656W 661W 667W 673W
Module Efficiency STC (%) 25.15% 25.37% 25.60% 25.82% 26.04%
25% Maximum Power (Pmax) 706W 713W 719W 725W 731W
Module Efficiency STC (%) 27.34% 27.58% 27.82% 28.07% 28.31%


G12R 565W 570W 575W 580W 585W 210-182mm Solar Cell Mono LECO N-Type BIFACIAL Half Cut Solar Panels


Full Pine-Sol All Black Frame 500watt 500 550W 600W 600 700 W 1000W Solar Monocrystalline Photovoltaic Panels
Full Pine-Sol All Black Frame 500watt 500 550W 600W 600 700 W 1000W Solar Monocrystalline Photovoltaic Panels
Full Pine-Sol All Black Frame 500watt 500 550W 600W 600 700 W 1000W Solar Monocrystalline Photovoltaic Panels
good quality solar panels
Packaging process:
Solar Panel Corner Protection→Independent Cardboard Box Packaging→Pallet→Wooden Box→PET Plastic Steel Packaging Belt→PE Winding Film
Full Pine-Sol All Black Frame 500watt 500 550W 600W 600 700 W 1000W Solar Monocrystalline Photovoltaic Panels

Product Size: 2279*1134*30mm

Package: 36pcs/Pallet: 20Pallets/720PCS/40HQ


About FGET



Future Green Techonology is committed to creating a green future.

Rooting ourselves in the new energy industry for decade, we manufacturehigh quality solar panel and battery and win high reputation from hundredscustomers globally.

We also have over 100 long-term partners around the world. We sell high-quality batteries and solar panels, and also customize solar panel systems and solar power stations for our customers who need them. If you also want to customize a solar panel system, you can submit your daily electricity consumption requirements below, and we will immediately develop a detailed energy solution for you.

Support Factory About Future Green



Q1: How to choose the right Panel?
A1: Tell us your demand, then our sales will recommend a suitable panel for you.


Q2: What's the difference between Mono and Poly panels?
A2: Monocrystalline solar panels have the highest efficiency rates since they are made out of the highest-grade silicon. The process used to make polycrystalline silicon is simpler and costs less. The amount of waste silicon is less compared to monocrystalline.

Q3: How about the delivery time?
A3: 7 days for sample; 15 days for bulk order.

Q4: What is the warranty for solar panels?
A4: 5 years warranty on FGET-Solar product.

Q5: How to solve the technical problem?
A5: 24 hours after-service consultancy just for you and to make your problem solve easily.
